Caractéristiques

• Frame: M5 Alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
• Seat Binder: Alloy, 38.6mm
• Rear Shock: FOX DHX Factory, Ride Dynamics Trail Tune, 210x55mm, S2: 400lbs, S3: 450lbs, S4: 500bs, S5: 550lbs, S6: 600lbs
• Fork: FOX FLOAT 38 Factory, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm QR axle, 44mm offset, 160mm of travel
• Front Brake: TRP DH-R EVO, 4-piston caliper, hydraulic disc, 220mm
• Rear Brake: TRP DH-R EVO, 4-piston caliper, hydraulic disc, 203mm
• Shift Levers: Shimano SLX, M7100, 12spd
• Rear Derailleur: Shimano SLX, M7100, SGS, 12-speed
• Cassette: Shimano SLX, CS-M7100, 12-speed, 10-51t
• Chain: Shimano SLX, M7100, 12-speed
• Crankset: Shimano SLX, M7120, 32T ring, 55mm chainline, S2-S3:165mm, S4-S6: 170mm
• Bottom Bracket: Shimano, BB-MT801, Threaded
• Rims: Roval Traverse, hookless alloy, 30mm inner width, tubeless ready, Front: 29, Rear: 27.5
• Front Hub: DT Swiss 370, 15x110mm, 28h
• Rear Hub: DT Swiss 370, 12x148mm, 32h
• Spokes: Sapim Force
• Front Tire: Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
• Rear Tire: Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 2Bliss Ready, 27.5x2.3"
• Inner Tubes: Standard, Presta valve
• Stem: Deity, 35mm clamp, 35mm length
• Handlebars: Deity, Racepoint, 5-degree upsweep, 9-degree backsweep, 810 width, S2: 25mm rise: S3-S6: 38mm rise
• Grips: Deity, Knuckleduster, Black
• Saddle: Bridge Comp, Hollow Cr-mo rails, S1-S2: 155mm, S3-S6: 143mm
• SeatPost: PNW Loam OE Dropper, tool-less travel adjust, Range lever, 34.9, S2: 150mm, S3: 170mm, S4-S6: 200mm
• SWAT: SWAT internal downtube storage
• Product ID: 257786
• Weight: 16.90 kg (37 lb, 4.1 oz)

Weight Size: S4
